※ Use for Yottacontrol Whole Series Controller ※ RS-485 Interface ※ Supports Modbus RTU ※ LED Indicator, Low Power Indicator ※ Operation Temperature -20~+75°C ※ Isolation Voltage: 5000 V DC ※ Surge , EFT And ESD Protection ※ Dual Watchdog Timer※ Dual Watchdog Timer ※ Operation Range: Up To 1200 Meters ※ Support Voltage, Current and sensor input ※ Support PNP/NPN, relay output ※ Free Monitor PC Software "SmartUtility" |
Product List
Specifications
| A-8012 | A-8019 |
| Operation Voltage: 10~30VDC/24VAC Inputs(Isolation): 2*isolation DI; status low<1VDC; high>8~30VDC Outputs: 2*(Souce Transistor) Continuous Current: 10-35VDC(1A) Communication Baud Rate: 2400~921600bps Isolation: YES(5000VDC) Input/Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Analog inputs: 4 (16-bit) Analog input Type: 2* 0/4~20mA + 2* PT-100/1000 Analog Outputs: 2 (12-bit) Analog Outputs Type: 0/4 ~20mA Input Impedance:Current: 100 Ω / RTD : 10 MΩ Input Accuracy: ±0.1% Interface: RS-485 + USB Channel Independent Configuration: YES Sampling Rate: 10 sample/second (total) CMR @ 50/60 Hz: 120 dB Span Drift: ±50 ppm/°C Zero Drift: ±18 μV/°C Temperature Ranges: (PT-100:-200~+600°C) (PT-1000:-200~+600°C) |
Operation Voltage: 10~30VDC/24VAC (J:-210~760°C) (K:-270~1,370°C) (T:-270~400°C) (E:-270~1,000°C) (R:0~1,750°C) (S:0~1,750°C) (B:0~1,800°C) (Thermistor-10K-T2:0~100°C) (Thermistor-10K-T3:0~100°C) (Thermistor-6.8K:-10~100°C) (Thermistor-4.7K:-10~100°C) (Thermistor-3.3K:-20~100°C) (Thermistor-3K:-20~100°C) (Thermistor-2.7K:-20~100°C) (Thermistor-2.252K:-20~100°C) (Thermistor-2.1K:-30~100°C) (Thermistor-2K:-30~100°C) (Thermistor-1.5K:-40~100°C) (Thermistor-1K:-40~100°C) |
| A-8051 | |
| Operation Voltage: 10~30VDC/24VAC Inputs(Isolation): 16 Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Input Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
|
| A-8055 | A-8055S |
| Operation Voltage: 10~30VDC/24VAC Inputs(Isolation): 8 Outputs: 8*(Sink Transistor) Continuous Current: 10-40VDC(200mA) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Input/Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
Operation Voltage: 10~30VDC/24VAC Inputs(Isolation): 8 Outputs: 8*(Souce Transistor) Continuous Current: 10-35VDC(1A) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Input/Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
| A-8057 | A-8058 |
| Operation Voltage: 10~30VDC/24VAC Outputs: 12*(Souce Transistor) Continuous Current: 10-35VDC(1A) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
Operation Voltage: 10~30VDC/24VAC Outputs: 12*(Sink Transistor) Continuous Current: 10-40VDC(200mA) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
| A-8060 | |
| Operation Voltage: 10~30VDC/24VAC Inputs(Isolation): 8 Outputs: 4*(Power Relay) Continuous Current: 250VAC(5A)/30VDC(5A) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Input/Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
|
| A-8068 | A-8069 |
| Operation Voltage: 10~30VDC/24VAC Outputs: 8*(Signal Relay) Continuous Current: 120VAC(0.5A)/30VDC(1A) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
Operation Voltage: 10~30VDC/24VAC Outputs: 8*(Power Relay) Continuous Current: 250VAC(5A)/30VDC(1A) Communication Baud Rate: 1200~115200bps Isolation: YES(5000VDC) Output Operating Frequency: 10HZ Operation Temperature: -20 to +75 °C Degree Of Protection: IP20 Interface: RS-485 Channel Independent Configuration: YES |
